Magnetic Coolant Separator

A magnetic coolant separator is a device used to remove ferrous particles from liquid coolants in industrial processes. It employs magnets to attract and separate magnetic contaminants, enhancing the efficiency and lifespan of coolant systems in machinery. For bulk orders and customized requirements, connect with trusted Magnetic Coolant Separator Manufacturers in India .

Magnetic Coolant Separator Manufacturers Model

35 LPM

Model – ‘CMS – 35’ Consisting of following features:

• Complete with powerful magnetic drum 140mm (L) × 120mm (dia.)
• Driven by continuously rated gear box with Electric motor
• Rubber roller
• Brass scraper plate
• Powder coated body

Model

50 LPM

Model – ‘CMS – 50’ Consisting of following features:

• Complete with powerful magnetic drum 190mm (L) × 150mm (dia.)
• Driven by continuously rated gear box with Electric motor
• Rubber roller
• Brass scraper plate
• Powder coated body

Model

65 LPM

Model – ‘CMS – 65’ Consisting of following features:

• Complete with powerful magnetic drum 270mm (L) × 150mm (dia.)
• Driven by continuously rated gear box with Electric motor
• Rubber roller
• Brass scraper plate
• Powder coated body

Model

100 LPM

Cap. – 100 LPM

Model – ‘CMS – 100’ Consisting of following features:

• Complete with powerful magnetic drum 390mm (L) × 150mm (dia.)
• Driven by continuously rated gear box with Electric motor
• Rubber roller
• Brass scraper plate
• Powder coated body

Model

150 LPM

Model – ‘CMS – 150’ Consisting of following features:

• Complete with powerful magnetic drum 450mm (L) × 150mm (dia.)
• Driven by continuously rated gear box with Electric motor
• Rubber roller
• Brass scraper plate
• Powder coated body

Model

200 LPM

Model – ‘CMS – 200’ Consisting of following features:

• Complete with powerful magnetic drum 545mm (L) × 150mm (dia.)
• Driven by continuously rated gear box with Electric motor
• Rubber roller
• Brass scraper plate
• Powder coated body

Model

400 LPM

Cap. – 400 LPM (Heavy Duty)

Model – ‘CMS – 400’ Consisting of following features:

• Complete with powerful magnetic drum 675mm (L) × 150mm (dia.)
• Driven by continuously rated duoble reduction gear box with Electric motor
• Rubber roller
• Brass scraper plate
• SS body

Model

500 LPM

Cap. – 500 LPM (Heavy Duty)

Model – ‘CMS – 500’ Consisting of following features:

• Complete with powerful Rare earth magnetic drum 750mm (L) × 150mm (dia.)
• Driven by continuously rated duoble reduction gear box with Electric motor
• Rubber roller
• Brass scraper plate
• Powder Coated body
